AUO 24Inch Industrial Lcd Model M240UAN01.0 1920X1200P 94PPI 300cd/M2 30PIN Desktop Lcd

  • 1
  • 2
  • 3

Brand Name : AUO

Model Number : M240uan01.0

Certification : Rohs,CE,FCC

Place of Origin : China

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W, Western Union, MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

resolution : 1920*1200pixels

style : 30PIN IPS

brightness : 300CD/M2

color : 16.7M

contrast ratio : 1000 :1

working life : 30K Hours

Type : lcm

Size : 24inch

Lamp type : WLED

Voltage : 12.0V

Contact Now

AUO 24Inch Industrial lcd model M240uan01.0 1920X1200P 94PPI 300cd/M2 30PIN Desktop lcd



       The M240UAN01.0 is a 24.0 inch diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcdin the following: sRGB, WLED Backlight, Upside I/F, Matte , TCO 7.0 Compliance. Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Industrial etc. According to the information stored in einklcd this model mass production on Q3, 2018, Now this model is in production. We inputted this model's specification on Jul 7 2016 for the first time, and the latest update on Aug 3 2023. If you want to embed M240UAN01.0 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail. The M240UAN01.0 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.





Brand
AUO
Model P/N
M240UAN01.0
Diagonal Size
24.0"
Panel Type
a-Si TFT-LCD, LCM
Resolution
1920(RGB)×1200, WUXGA 94PPI
Pixel Format
RGB Vertical Stripe
Active Area
518.4(W)×324(H) mm
Bezel Opening
522.4(W)×328.0(H) mm

Outline Size 546.4(W)×352(H) ×12.2(D) mm Surface Antiglare (Haze 25%)
Brightness 300 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10)  Display Mode AHVA, Normally Black, Transmissive
Best View on Symmetry Response Time 14 (Typ.)(G to G)
Display Colors 16.7M 100% sRGB Lamp Type 10S4P WLED , 30K hours , Without Driver
Frequency 60Hz  Touch Screen Without
Panel Weight 2.53Kgs (Typ.) Application
Signal Interface LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage 12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
