LQ201U1LW32 Industrial LCD Display Medical Imaging Monitor 1600*1200 Pixels 30 Pin

Product Categories
FOCUS VISION TECHNOLOGY LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

LQ201U1LW32 Industrial LCD Display Medical Imaging Monitor 1600*1200 Pixels 30 Pin

  • 1
  • 2

Brand Name : sharp

Model Number : LQ201U1LW32

Certification : Rohs,CE,FCC

Place of Origin : China

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W, Western Union, MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

resolution : 1600*1200

style : 30PIN IPS

brightness : 260 CD/M2

color : 16.7M

contrast ratio : 1400 :1

Contact Now

  • Manufacturer
  • Sharp
  • Model Name
  • LQ201U1LW32
  • Screen Size 20.1 inch
  • Screen Type LCM, a-Si TFT-LCD
  • Pixel Number 1600(RGB)×1200 (UXGA)
  • Arrangement RGB Vertical Stripe
  • Active Area(mm) 408 × 306 (H×V)
  • Outline(mm) 436 × 335 × 20.4 (H×V×D)
  • Bezel Area(mm) 413.2 × 311.2 (H×V)
  • Treatment Antiglare, Hard coating (2H)
  • Luminance 260 cd/m² (Typ.)
  • Contrast Ratio 1400 : 1 (Typ.) (TM)
  • Viewing Angle 85/85/85/85 (Typ.)(CR≥10)
  • Response 30 (Typ.)(Tr+Td) ms
  • Good View at Symmetry
  • Work ModeVA, Normally Black, Transmissive
  • Color Depth16.7M 71% (CIE1931)
  • BacklightWLED , 50K hours , With LED Driver
  • Mass2.40Kgs (Max.)
  • Used for
  • Refresh Rate60Hz
  • TouchscreenWithout
  • Signal Type
  • LVDS (2 ch, 8-bit) , Connector , 30 pins
  • Voltage Supply
  • 12.0V (Typ.)
  • Max. Ratings
  • Storage Temp.: -25 ~ 60 °C Operating Temp.: 0 ~ 50 °C

LQ201U1LW32 Industrial LCD Display Medical Imaging Monitor 1600*1200 Pixels 30 PinLQ201U1LW32 Industrial LCD Display Medical Imaging Monitor 1600*1200 Pixels 30 PinLQ201U1LW32 Industrial LCD Display Medical Imaging Monitor 1600*1200 Pixels 30 PinLQ201U1LW32 Industrial LCD Display Medical Imaging Monitor 1600*1200 Pixels 30 PinLQ201U1LW32 Industrial LCD Display Medical Imaging Monitor 1600*1200 Pixels 30 PinLQ201U1LW32 Industrial LCD Display Medical Imaging Monitor 1600*1200 Pixels 30 Pin



   All Origianl product will be send to customer after full test one by one.

  • Spec details can be send to you via email,please contact us.
